The ultrasonic level meter is the intelligent non-contact liquid level measuring instruments. Product has automatic power adjustment, gain control, to a false target, and temperature compensation. U.S. imports of chip processing and advanced testing computing technology to improve the measurement accuracy of the instrument, for the interference signal suppression function to ensure that the real measurement results. The products can be widely used for a high degree of measurement of the level of a variety of liquid and solid materials can also be used for distance measurement.

Range	0.5~30m
Accuracy	0.25%, 0.5%
Resolution	Range<10m:1mm; >10m: 10mm
Frequency	~40KHZ
Launch Angle	6o - 12o
Blind Area	0.20~0.9m
LCD Display	Available
Supply Voltage	220VAC/24VDC
Output Signal	4~20mA Standard (Or optional RS485.RS232 when ordering)
Maximum Load	750 Ohm
Case Material	PA6.ABS
Degree of Protection	IP65.IP67.IP68
Ambient Temperature (oC)	-20~+55
Mounting Thread	M66x3, as required
